Earth with Europe and Africa in view, a few small satellites overhead with the circles they cover, and sensors on the ground linked to the satellite passing over them

Back to the home page

03 · RESEARCH TOPIC

Direct-to-Satellite IoT

A sensor on a farm or a buoy at sea can send its data straight to a satellite. I design the small constellations that serve such devices, and the radio access that lets low-cost, battery-powered hardware use them.

Large parts of the planet have no mobile coverage: oceans, deserts, farmland, forests. A sensor there can still send a few bytes at a time straight to a satellite overhead, using low-power radios such as LoRa that were designed for networks on the ground.

Keeping every point under a satellite at all times takes many satellites. If devices can wait for the next pass, a handful is enough, and the cost falls. I design these sparse constellations and the protocols that let thousands of devices share a short pass, much of it in the ANR project STEREO with Kinéis, a French operator of satellites for the Internet of Things, and French laboratories.

Wait for the next pass

A sensor can only send while a satellite is in view. With a sparse constellation that happens a few minutes at a time, and in between the sensor sleeps and keeps its readings. How long it waits depends on where it is and on the constellation, here one of those designed in our study.

The constellations as published

From Sparse Satellite Constellation Design for Global and Regional Direct-to-Satellite IoT Services (IEEE TAES 2022): for each region and each longest wait that devices can accept, the smallest constellation the design algorithm found. All orbits are circular and 700 km up, and a satellite counts as in view from 5° above the horizon (§V-A).

Region, longest wait allowedSmallest constellation foundSource
Whole planet to 80° N and S, 186 min5 satellites in 5 planes at 62.9°Fig. 7, Table III
Africa, 60 min12 satellites in 4 planes at 25°Fig. 12
Africa, 120 min4 satellites in 4 planes at 25°Fig. 12
Africa, 186 min3 satellites in 3 planes at 25°Fig. 12
Europe, 60 min12 satellites in 4 planes at 65°Fig. 12
Europe, 120 min4 satellites in 4 planes at 65°Fig. 12
Europe, 186 min3 satellites in 3 planes at 85°Fig. 12
Brazil, 120 min3 satellites in 3 planes at 25°; longest wait found, 97 minTable V
Greenland, 120 min2 satellites in 2 planes at 70°; longest wait found, 93 minTable V

Results, with sources

These are simulation results, under the assumptions set out in each paper.

Tools and projects

Selected papers

  1. DORSAL: Downlink Optimization for Robust Direct-to-Satellite LoRaWAN Juan A. Fraire, Oana Iova, Carlos Fernandez Hernandez, Fabrice Valois, Hervé Rivano, Cesar Azurdia-Meza, Marcos Diaz, Miguel Gutiérrez Gaitán, Diego Dujovne, Samuel Montejo Sánchez, and Richard Demo Souza IEEE Internet of Things Journal, 2026
    Abstract

    Delivering downlink (DL) ACKs to Class A LoRaWAN devices via low Earth orbit (LEO) satellite constellations requires predicting end-to-end propagation delays of 10–500 ms to hit a 1-s receive window, a timing challenge absent from terrestrial schedulers. We present downlink optimization for robust direct-to-satellite LoRaWAN (DORSAL), the first mixed-integer linear programming (MILP) scheduler for DL delivery in direct-to-satellite (DtS) LoRaWAN networks. It introduces the downlink arrival receive-window timing (DART) as the central constraint to jointly optimize gateway (GW) selection and packet injection timing across ISL-capable and bent-pipe architectures. Evaluation on a Walker 5× 5 polar constellation (25 satellites, 650 km) and a commercial ground station (GS) network yields five results: 1) DART infeasibility blocks 73% of bent-pipe deliveries regardless of scheduler quality: DART-unaware approaches collapse from 93% nominal to only 20% real delivery; 2) ISL routing raises %ACK by + 67.4 pp over bent-pipe (91.6% versus 24.2% at n_mathrm GS=3 ground stations, ISM band) by eliminating the three-way simultaneous-visibility constraint, with 73% of ACKs delivered via ≥ 2 -hop paths; 3) ISL %ACK is nearly flat across n_mathrm GSin 3,6,12 GSs (91.6%–92.7%), showing that a minimal three-station polar network captures the full scheduling benefit of an ISL-equipped constellation; 4) ISL hardware speed has negligible impact up to 300 ms/hop: %ACK is flat from 0 to 300 ms, then degrades in two discrete steps (−5.3 pp at 500 ms, −2 pp at 700 ms) as successive hop-count tiers lose causal injection feasibility; and 5) the MILP solves to proven optimality within seconds for up to 10^3 devices, confirming that the sparse conflict-graph structure keeps the problem tractable at realistic Internet of Things (IoT) subscriber counts.

  2. On the role of machine learning in satellite internet of things: A survey of techniques, challenges, and future directions Alexander Ylnner Choquenaira Florez, Juan A. Fraire, Hannah B. Pasandi, and Hervé Rivano Elsevier Computer Networks, 2025
    Abstract

    The drive towards an interconnected world via satellites is reshaping the landscape of communication technologies. This survey comprehensively reviews studies in the Satellite Internet of Things (SIoT) domain, focusing on the role of Machine Learning (ML) techniques. Indeed, the global data collection scale in SIoT is ideally suited for data-intensive and sophisticated ML approaches. We highlight the innovative use of ML to address specific SIoT challenges, aiming to identify current trends, methodologies, and outcomes. We considered theoretical, practical, and experimental research, organizing existing publications into a new taxonomy that intersects ML and SIoT categories. Our taxonomy reveals that Deep Learning (DL), Reinforcement Learning (RL), and Federated Learning (FL) are widely applied to address radio access schemes, resource and network management, and application-specific issues. This survey identifies critical gaps in current research on ML applications in SIoT, such as the lack of differentiation between space-based and ground-based processing, insufficient integration of SIoT-specific metrics, and the oversight of limited computational resources on orbiting satellites. These issues raise concerns about the feasibility and efficiency of proposed solutions. We propose promising research directions based on the derived insights to effectively bridge the gap between ML researchers and industrial SIoT entities.

  3. Space-Terrestrial Integrated Internet of Things: Challenges and Opportunities Juan A. Fraire, Oana Iova, and Fabrice Valois IEEE Communications Magazine, 2022
    Abstract

    Large geographical regions of our planet remain uncovered by terrestrial network connections. Sparse and dense constellations of near Earth orbit satellites can bridge this gap by providing Internet of Things (IoT) connectivity on a worldwide scale in a flexible and cost-effective manner. This article presents STEREO: a novel space-terrestrial integrated IoT architecture spanning direct- and indirect-to-satellite access from IoT assets on the surface. Framed on the identified requirements, we analyze NB-IoT and LoRa/LoRaWAN features to put these technologies forward as appealing candidates for future satellite IoT deployments. Finally, we list and discuss the key open research challenges to be addressed in order to achieve successful space-terrestrial IoT integration.

  4. Sparse Satellite Constellation Design for Global and Regional Direct-to-Satellite IoT Services Gabriel Maiolini Capez, Santiago Henn, Juan A. Fraire, and Roberto Garello IEEE Transactions on Aerospace and Electronic Systems, 2022
    Abstract

    In this article, we introduce and design sparse constellations for direct-to-satellite Internet of Things (DtS-IoT). DtS-IoT does not require a ground infrastructure, because the devices are directly connected to low earth orbit satellites acting as orbiting gateways. The key idea of sparse constellations is to significantly reduce the number of in-orbit DtS-IoT satellites by a proper dimensioning of the delivery delay anyway present in resource-constrained IoT services and an optimal positioning of the orbiting gateways. First, we analyze long-range modulation (LoRa)/LoRaWAN and narrowband Internet of Things (NB-IoT) standards and derive realistic constraints on the maximum gap time between two consecutive passing-by satellites. Then, we introduce and optimize an algorithm to design quasi-optimal topologies for sparse IoT constellations. Finally, we apply our design to both global and regional coverage and we analyze the tradeoff between latency, number of orbit planes, and total number of satellites. Results show that sparse constellations can provide world-wide IoT coverage with only 12.5 and 22.5% of the satellites required by traditional dense constellations considering 3 and 2-h gaps. Also, we show that region-specific coverage of Africa and Europe can be achieved with only four and three satellites for LoRa/LoRaWAN and NB-IoT, respectively.

  5. Direct-To-Satellite IoT - A Survey of the State of the Art and Future Research Perspectives - Backhauling the IoT Through LEO Satellites Juan A. Fraire, Sandra Céspedes, and Nicola Accettura International Conference on Ad-Hoc Networks and Wireless (ADHOC-NOW), 2019
    Abstract

    The Internet of Things (IoT) has drawn an enormous attention into the scientific community thanks to unimaginable before applications newly available in everyday life. The technological landscape behind the implied surge of automated interactions among humans and machines has been shaped by plugging into the Internet very low power devices that can perform monitoring and actuation operations through very cheap circuitry. The most challenging IoT scenarios include deployments of low power devices dispersed over wide geographical areas. In such scenarios, satellites will play a key role in bridging the gap towards a pervasive IoT able to easily handle disaster recovery scenarios (earthquakes, tsunamis, and flash floods, etc.), where the presence of a resilient backhauling communications infrastructure is crucial. In these scenarios, Direct-to-Satellite IoT (DtS-IoT) connectivity is preferred as no intermediate ground gateway is required, facilitating and speeding up the deployment of wide coverage IoT infrastructure. In this work, an in-depth yet thorough survey on the state-of-the-art of DtS-IoT is presented. The available physical layer techniques specifically designed for the IoT satellite link are described, and the suitability of both the current Medium Access Control protocol and the upper layer protocols to communicate over space links will be argued. We also discuss the design of the overall satellite LEO constellation and topology to be considered in DtS-IoT networks.

All papers on satellite IoT

People and partners

With Kinéis IRIT · LAAS · LIG · Politecnico di Torino · Universidad de Chile · UC Berkeley Funding ANR STIC-AmSud
